9203509001 - ACI 4420 HH - Axial Fan 119x119x38mm 230VAC 175m³/h IP20, ebmpapst, new bulk

1 General
Fan type: Fan
Rotating direction looking at rotor: Clockwise
Airflow direction: Air outlet over struts
Bearing system: Ball bearing
Mounting position - shaft: Any

2 Mechanics
2.1 General
Width: 120 mm
Height: 120 mm
Depth: 38,0 mm
Diameter: 0,0 mm
Mass: 0,275 kg
Housing material: Plastic
Impeller material: Plastic

Max. torque when mounted across both mounting
flanges
Wire outlet corner: 50 Ncm
Remaining corners: 80 Ncm

Screw size: ISO 4762 - M4 degreased, without an additional
brace and without washer
Rotor protrusion max.: 0,6 mm

2.2 Connections
Electrical connection: Plug
Lead wire length: L = 0 mm
Tube length: See drawing
Wire size (AWG): 22

Plug: See drawing
Contact: See drawing

Land van herkomst Hongarije (HU)
Fabrikant: ebmpapst
Gross weight (incl. package) 275 Gram
Dimensions (incl. package) 38 x 119 x 119 MM
9203509001
VWC0120YSGBS
ACi 4420 HH

Datasheet: bekijk hier
Product video: bekijk hier
